Servo Model Cnc Machine

With the years of experience and vast knowledge, we are involved in manufacturing, supplying, trading and distributing a wide range of Servo Model CNC Machine in Ahmedabad, Gujarat, India.

Sr. No. Technical Parameter Unit Technical Parameter
1 Drive Motors Stapper
2 Controls Digital Signal Processor
3 X-Y Movement Rack & Pinion, Gear Drive,Taiwan
4 Z Movement Ball Screw Drive, Germany
5 Computer interface USB 2.0
6 Command Code G Code
7 Spindle HSD 6kw, Air Cooling, 18000 RPM, Italy
8 Oil Lubrication System Standard
9 Working Voltage AC 380V / IIz,3 A
10 Software Optional
11 Maximum Speed mm/min 35000
12 Resolutions mm 0.025
13 X-Y-Z Axis Working Area mm 1220 x 2440 x 180
14 Maximum Cutting Speed mm/min 25000
15 Collet Type & Size mm ER 32 (12.7, 6, 3.175)
16 Machine Size mm 1750 x 2760
17 Packing Dimensions mm 3160 x 1860 x 1720
18 Approx. Weight kgs 1250 kg (appx)
