Series & Parallel Centrifugal Pump Test - Application: Fluid Mechanics Equipment

Product Description
The setup comprises of two centrifugal pumps assembly with interconnecting pipe works.
It is installed with necessary pressure gauges and flowmeter for pump performance study.
This unit is mounted on a support plate which can be used in a stand-alone operation.
The apparatus aims to study the operating behavior of centrifugal pumps as a single pump; in series condition; in parallel condition; capture various pump characteristic curves and pump efficiencies
Specifications:
Pump (2 units) Type: Centrifugal Pump; Max head: 21 meters of Water; Max flow: 90 LPM
Reservior Tank: Cylindrical, transparent tank; Volume: 20 L
Pressure gauge: Delivery side: 0 to 7 bar; Suction side: 0-760 mm of Hg
Flow Rotameter Size: 1 Range : 0 to 150 LPM
Digital Energy meter to measure input power
Digital RPM Indicator
Variable Frequency Drive
Emergency Switch
Detailed technical manual
