Scs3000 Spray Coating System Power Source: Electricity

Features:
a c Ease of programming with PC-based Dispensing Software
a c Purging stations for material
a c 3 different spray patterns to choose from
a c External control panel with easy button access
a c Easily customized to suit various types of applications

Gantry Robot:
Working Area: 300 x 300 x 100mm
Programming Method: PC Based Software
Maximum Speed: 600 mm/sec
Resolution: 2Aum per axis
Repeatability: A 10Aum per axis
Drive System: AC Servo Ball Screw
Program Capacity: Unlimited

Other sizes available
SCS4000: 400 x 400 x 100mm

Spray Valve
Operating Air Pressure: More than 4.0 kgf/cm
Material Delivery Pressure: Max 6.0 kgf/cm
Maximum Cycle Rate: 400 Cycles/min Full Stroke
Repeatability: A 10Aum per axis

Types of spray nozzles available:
- Narrow Cone (SV100NC)
- Wide Cone (SV100WC)
- Flat Cone (SV100FC)

Optional Features:
* Simultaneous Multiple- Head Spraying
* Solvent purging station
* Material tank with heater & various tank sizes available
