Screen Filter By Dhanushri Industries

Screen Filter

Mild Steel Construction
Powder coated with 70 to 80 micron thick deep blue Colour (Or selected Colour) pure polyester coated from inside and out side surface for protection against corrosion And weather effects.
Easy to open and clean.
Tangential inlet prevents the tearing of stainless steel screen on direct impact & abbrrasion of heavy particles available in standard mesh 150 micron size (Other mesh size available on request)
Maximum Operating pressure 10 Kg/cm2
Standard end connection are BSP male thread.
Manufactured as per IS : 12785





Model
Height (H)
Body Height (H)
Weight (W)In Kg
Connection


DSF - 10m3
430
190
8.5
2"


DSF - 20m3
560
330
10.5
2"


DSF - 30m3
635
390
12.5
2 1/2"


DSF - 40m3
720
480
14
3"
