Sami Automatic 1000 Twin Column - 12300x67x1.6mm Blade, 1000x1000mm Cutting Capacity, 0.1mm Accuracy | Hydraulic Feed, Twin Column Guide, Fast Precise Cuts

We are the loyalist in manufacturing and supplying an extensive assortment of Sami Automatic 1000 Twin Column in Dewas, Madhya Pradesh, India.

Cutting Capacity: - Square - 1000x1000mm & Round 1000mm.
Clamping Capacity:- 200mm. to 1000mm.
Cutting Accuracy & Cut Face:- 100mm 0.1mm.
Cutting Speed: - 20 to 100 mtr./min.
Hardness to be cut: - 70 to 350 BHN.
Maximum weight can be placed on the machine:- 8Tons.
Bi-Metallic Band Saw Blade: - 12300x67x1.6mm.
Floor area for machine:- 6100x2175mm.
Stress relieved torsion free fabricated bed.
The Machine is provide with Hydro mechanical Sensor to locate hard spot in the cutting material And to adjust feed accordingly to avoid damages to Blade and Machine.
Cutting arm guided in two vertical hardened & ground columns and hard chrome plated.
Infinitely variable pressure controlled cutting feed and upward return rapid movement by hydraulic cylinder.
Automatic height adjustment for saw frame to save cycle time.
Tungsten carbide face guides with ball bearings.
Adjustable & Movable Dovetail type Heavy duty Movable Blade guide.
Manually adjusted (by thumb screw) carbide tipped blade guide with bearing for perfect match.
Separate Bearing housing being provided to absorbed the axle load due to hydraulic tensioning.
High Efficiency Power transmission the machine is provided with Helical Gear Box Model- 10.5 SNU Modified.
Cutting feed synchronizes to Band speed. If you reduce band speed automatically cutting feed will reduce.
