Radar Beacon
Price:
Get Latest Price
In Stock
Product Specifications
| Azimuth Response | Horizontal, Hor & Ver |
| Code Duration | 35-56 microseconds |
| Features | Wide range, Accurate signal, Long response, High sensitivity, Programmable code, Advanced SLS, Durable, Reliable |
| Frequency Accuracy | ±3 MHz |
| Ingress Protection | IP65, IP66 |
| Input Voltage | 9-24V DC |
| Operating Frequency | 9.3-9.5 GHz, 2.9-3.1 GHz |
| Output Power | 30 dBm, 28 dBm |
| Pulse Power | 1.0 watt |
| Pulse Width | 100-1700 nsec |
| Quiescent Power | 35 mA |
| Response Code | Programmable Morse code |
| Response Delay | 650 nsec |
| Response Rate | 10 kHz |
| Size | 300mm dia, 780mm height |
| Surge Protection | IEC 61000-4-5 |
| System Sensitivity | -40 dBm, -32 dBm |
| Temperature Range | -20°C to +60°C |
| Weight | 20 kgs |
Product Overview
Key Features
* Operating Frequency:
o 9.3 GHza 9.5 GHz (X-band)
o 2.9 GHza 3.1 GHz (S.Band)
* Frequency Accuracy: A 3 MHz
* Pulse Power:1.0 watt
* Pulse width Response:
o Min: 100 n sec
o Max: 1700 n sec
* Response Rate:10 K Hz max.
* Response Delay: 650 n sec max.
* System Sensitivity:
o -40 dBm,(X - band)
o -32 dBm,(S - band)
* Output Power to Antenna:
o 30 dBm, (X - band)
o 28 dBm, (S - Band)
* Response Code: Programmable morse code
* Code Duration: 35 to 56 microseconds
* Azimath Response:
o Horizontal,(X-band)
o Hoz & Vertical,(S - band)
* Side Lobe Suppression: Advanced SLS
* Temperature Range:- 20A to + 60A C
* Input Voltage: 9V to 24V d.c. (12V nominal)
* Quiescent Power:35 m A
* Surge Protection: IEC 61000-4-5 class 4 level
* Ingress Protection: IP 65, IP66 level
* Size: 300mm dia, 780mm height
* Weight: 20 kgs. (approx).
o 9.3 GHza 9.5 GHz (X-band)
o 2.9 GHza 3.1 GHz (S.Band)
* Frequency Accuracy: A 3 MHz
* Pulse Power:1.0 watt
* Pulse width Response:
o Min: 100 n sec
o Max: 1700 n sec
* Response Rate:10 K Hz max.
* Response Delay: 650 n sec max.
* System Sensitivity:
o -40 dBm,(X - band)
o -32 dBm,(S - band)
* Output Power to Antenna:
o 30 dBm, (X - band)
o 28 dBm, (S - Band)
* Response Code: Programmable morse code
* Code Duration: 35 to 56 microseconds
* Azimath Response:
o Horizontal,(X-band)
o Hoz & Vertical,(S - band)
* Side Lobe Suppression: Advanced SLS
* Temperature Range:- 20A to + 60A C
* Input Voltage: 9V to 24V d.c. (12V nominal)
* Quiescent Power:35 m A
* Surge Protection: IEC 61000-4-5 class 4 level
* Ingress Protection: IP 65, IP66 level
* Size: 300mm dia, 780mm height
* Weight: 20 kgs. (approx).
