Process Co Analyzer
Price:
Get Latest Price
In Stock
Product Specifications
| Accuracy | <2%FS |
| Dimensions | 155x155x290mm |
| Display | LCD |
| Features | Accurate readings, Easy operation, Reliable results, Durable design, Versatile applications, Wide measuring range, Multiple outputs, Simple calibration |
| Material | Aluminum |
| Output | 4-20mA |
| Power | 85-264VAC |
| Range | 0-30%CO |
Product Overview
Key Features
Our firm is manufacturing and supplying of Process CO Analyzer to our patrons with the following specification:
Measure Range: 0-30% CO FS ranges;
Accuracy: Application: CO analysis from 0.01% to 30% in inert gases,
mixed gases, gas streams, etc.;
Approvals: ISO9001:2008;
Area Classification: General purpose;
Alarms: 1 adjustable form C relay contacts non-latching;
Compensation: Barometric pressure and temperature; optional
heated sample system and sensor housing;
Connections: 1/4a a or 1/8a a compression tube fittings;
Controls: Menu driven calibration, alarm and system
functions;
Data Acquisition: Selectable data point intervals;
Display: Graphical LCD 128A 64MM;
Enclosure: Painted aluminum 155(H)A 155(W)A 290MM(D);
Flow Sensitivity: 300~600ml/min recommended;
Pressure: Inlet - regulate to 0.05MPa~0.35MPa,
Vent a atmospheric;
Power: Universal; 85~264 VAC, 50/60Hz;
Response Time: 90% of final FS reading < 50 seconds;
Sample System: Flow control; flow indicator;
Sensor Life: 36 months at 25a and 1 atm;
Signal Output: 4-20mA isolated or 0-10V (optional);
Temp. Range: 0~45 a ;
Warranty: 12 months analyzer; 12 months sensor;
Measure Range: 0-30% CO FS ranges;
Accuracy: Application: CO analysis from 0.01% to 30% in inert gases,
mixed gases, gas streams, etc.;
Approvals: ISO9001:2008;
Area Classification: General purpose;
Alarms: 1 adjustable form C relay contacts non-latching;
Compensation: Barometric pressure and temperature; optional
heated sample system and sensor housing;
Connections: 1/4a a or 1/8a a compression tube fittings;
Controls: Menu driven calibration, alarm and system
functions;
Data Acquisition: Selectable data point intervals;
Display: Graphical LCD 128A 64MM;
Enclosure: Painted aluminum 155(H)A 155(W)A 290MM(D);
Flow Sensitivity: 300~600ml/min recommended;
Pressure: Inlet - regulate to 0.05MPa~0.35MPa,
Vent a atmospheric;
Power: Universal; 85~264 VAC, 50/60Hz;
Response Time: 90% of final FS reading < 50 seconds;
Sample System: Flow control; flow indicator;
Sensor Life: 36 months at 25a and 1 atm;
Signal Output: 4-20mA isolated or 0-10V (optional);
Temp. Range: 0~45 a ;
Warranty: 12 months analyzer; 12 months sensor;
