Pressure And Temperature Gauges - Non Ferrous Bourdon, 50-250 Mm Dial Size, Dust & Weather Proof, High Accuracy +1%

We are involved in manufacturing and supplying a quality range of Pressure and Temperature Gauges in Mumbai, Maharashtra, India. High mechanical strength and durability, these are viewed as some of the salient characteristics of these products. Additionally, customers can grab these Temperature Gauges from us at manageable prices.

Details

1. PRESSED STEEL PRESSURE GAUGE
Dial size : 50, 63, 100 & 150 mm.
Bourdon, Movement & Block : Non ferrous.
Accuracy : +2%, Pressed Steel Case & Cover.
Connection : 3/8" BSP.
Ranges : 1kg/cm2 to 600 kg/Cm2 with psl scale, -760 mmhg (vaccum) and compound ranges.
2. DUST & DAMP PROOF PRESSURE GAUGE
Dial size : 100 & 150 mm.
Bourdon, Movement & Block : Non Ferrous.
Accuracy : + 1 % Cast aluminium case with screwed inner bezel of ABS plastic.
Connection : 3/8" BSP.
Mounting: Projection/ Direct with bottom entry.
Ranges: 1kg/cm2 to 250 kg/cm2 with psl scale,-760 mmhg and compound ranges.
3.CAST ALUMINIUM WEATHER PROOF PRESSURE GAUGE
Dial size : 100, 150 & 250 mm.
Boudon : Non ferrous /SS 316. Movement : Non ferrous/ SS 304, Block : Extruded brass/ SS 316-
Accuracy : + 1% 0.5%, Micro zero adjustment pointer & blow out disc.
Case : Cast aluminium weather proof with screwed inner bezel of ABS plastic
Connection : 33/8 " BSP< 1/2" NPT,1/2"BSP (M)
