Power Meter - 96mm X 96mm X 125mm Dimensions, True Rms Measurement With Computer Interface, 3 Phase 3/4 Wire Programmable, Peak Value Monitoring & True Power Display

True RMS measurement. Power in KW, KVA.
PT and CT primary programmable at site.
3 phase- 3 wire or 3 phase - 4 wire programmable at site.
Displays - True Power ( KW) , Current (Amps) PF with lead/Lag indication, Frequency (Hz) and active energy
Communication facility with computer.

EXTRA FEATURES WITH COMPUTER INTERFACE
SIX different Time of Day (TOD) settings.
TOD - True energy and Average PF.
Peak value Monitoring- Current, Voltage & True Power.
Monitoring of PT and CT Failures
Monitoring of no load and over load operations.

PMR a 5A a KW, KVA, PF, KWHr a 3Phase, 3 Wire or 4 Wire system
PMR a 6 a KW, Amps, PF, KWHr- 3Phase, 3 wire or 4 wire system
PMR - 5 a KW,KVA,PF Hz, KWHr, 3Phase, 3 wire or 4 Wire system


Current 5A / 1A
AUX SUPPLY 85 to 265V AC
ACCURACY CLASS 1
DISPLAY 6 Digit super bright LED display
BURDEN 0.1 VA typical
DIMENSIONS 96mm x 96mm x 125mm
PANEL CUTOUT 90mm x90mm
KEYBOARD Feather touch key board
