Polarizing Microscope With Built-in Focusable Bertrand Lens
Price Trend: 68000.00 - 98000.00 INR / Number
Get Latest Price
Minimum Order Quantity :
1 Number
In Stock
Product Specifications
| Stage | Rotating, 140mm |
| Focusing | Coaxial |
| Illuminator | Koehler, 20W |
| Objectives | 4x, 10x, 40x |
| Eyepieces | 10x paired |
| Polarizer | Rotatable |
| Condenser | Abbe, N.A 1.25 |
| Usage | Research, material analysis |
| Features | High resolution, Precise focus, Versatile, Durable design, Easy operation, Koehler illumination |
| Payment Terms | Cash in Advance (CID) |
| Supply Ability | 100 Per Week |
| Delivery Time | 10 Days |
| Packaging Details | Export Quality Cartons |
| Main Export Market(s) | Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa |
| Main Domestic Market | All India |
| Certifications | An ISO 9001:2015, 14001:2015, 13485:2016, FDA, WHO-GMP, CE, & BIS Certified Company |
Product Overview
Key Features
Research Polarizing Microscope Compact Ball bearing Rotating Stage, 140mm dia., graduation with vernier, lock & stage specimen clips.
Focusing - Coaxial focusing is provided with coarse tension adjustment ring and graduated slow motion knobs. Adjustable safety lock is attached to prevent the breakage of specimen slides.
Illuminator- Koehler's Illuminator with pre-centered 20W Tungsten Halogen source & integral electric transformer with intensity control. Input Voltage 220 or 110V.
Intermediate
Tube - Built-in focusable Bertrand Lens with center adjustment. Built-in Analyzer removable from optical part. Analyzer can be rotated 90A A with vernier reading to 6'. Compensator 1 Lambda, 1/4 Lambda & Quartz Wedge can be inserted in the tube as per requirement.
Compensator-Gypsum (1st. order red compensating plate, 560nm). Mica (145nm) & Quartz Wedge (I-IV order).
Objectives-Stress less flat achromatic DIN Objectives PF4x/0.10, PF10x/0.25 & PF40x/0.65 SL
Eyepieces-HKW10x Paired & WF 10x Cross
Polarizer-Fully rotatable Polarizer on a strain free N.A 1.25 abbe condenser with iris diaphragm.
Optional
Accessories-Detachable Mechanical Stage, Objectives PF20x & PF60X, Micrometer Eyepiece WF10x, Microphotographic Equipment, 30A A Inclined Siedentopf Heads. Wooden storing cabinet etc.
