Plain Plug Gauges - Iso 228 & Is: 2643 Standards | Durable, High Efficiency, Dimensions From 0.1 Mm To 1000 Mm

We design and develop an array of plain plug gauges. These gauges are manufactured considering the different factors like end depth, concentricity, squareness, etc. Our products are available in a variety of dimensions. Our plain plug gauges are durable and yield higher efficiency. Manufacturing range is .1 mm to 1000 mm Std gauges in H7, H8 available ex-stock.

-->B.S.P/B.S..P.F SCREW GAUGES PRICE INFORMATION(in US $) <---
I ) INDIAN STANDARD ->
Basic dimensions:
IS: 2643 Part I TO-III1975
IS:1
0216-1998
Gauging Practice: IS:1
0216-1998

II)INTERNATIONAL STANDARD ->
Basic dimensions:
ISO: 228 Part I -1994(E)
Gauging Practice:
ISO: 228 Part II -1987(E)
CLASS OF FIT GENERAL FOR PLUGS
CLASS B OR CLASS A FOR RINGS


ND----|---TP I |---|SP D/E Go &|-----|SR Go or|
in------|-----------|NoGo 6H|----------|NOGO 6g|
inch
G 1/16"|--|28|--|100$|--|149$
G 1/8"|--|28|--|39$|--|83$
G 1/4"|--|19|--|39$|--|83$
G 3/8"|--|19|--|39$|--|83$
G 1/2"|--|14|--|40$|--|117$
G 5/8"|--|14|--|49$|--|117$
G 3/4"|--|14|--|49$|--|117$
G 7/8"|--|14|--|49$|--|117$
G 1"|--|11|--|69$|--|149$

*ND->Nominal Dimension ,SP->Screw Plug ,SR->Screw Ring
