Peeling Tester
Get Latest Price
In Stock
Product Specifications
| Sealing Temperature | 250°C |
| Temp Accuracy | 0.2°C |
| Sealing Pressure | 0.7MPa |
| Load Cell | 200N |
| Accuracy | 0.5 FS |
| Dimensions | 1100x390x420mm |
| Power | 220V, 50Hz |
| Standards | ASTM F1921 |
| Usage | Material peel strength testing |
| Features | Integrated tests, Precise control, Easy operation, Reliable results, Durable design, Safety features |
Product Overview
Key Features
Features:-
1. peeling, tensile, hot tack, heat seal are integrated in one instrument
2.Sealing jaws are controlled by P.I.D. temperature. Temperature rises fast to set temp and keeps stable
3.7 inch TFT touching screen for easy operation
4.PLC control
5.Aluminum encapsulated sealing jaws for average heating
6.Multi-group parameter saving
7.Any testing speed adjustable
8.Auto zeroing, overload and over travel protection
9.Manual and foot switch starting test, anti-scald design
10.RS 232 port and professional software
Technical Specifications:-
Sealing Temperature : Ambient~250a
Temp Accuracy : A 0.2a
Heat Seal Dwell Time : 0.1~9999s
Hot Tack Dwell Time : 0.1~9999s
Sealing Pressure : 0.15MPa~0.7MPa
Sealing Jaws : 50mmx10mm PTFE Coated
Sealing Jaws Heating : Double Heating
Load Cell : 200N(Optional:30N50N100N500N)
Accuracy : 0.5 F.S.
Resolution : 0.01N
Stroke : 500mm
Gas Source : 0.5MPa~0.7MPa
Port Size : 6mm PU Hose
Dimensions : 1100mm(L)A 390mm(W)A 420(H)
Power : AC220V50Hz
Peeling Tester Standards : ASTM F1921, ASTM F2029, QB/T2358, YBB 00122003
