P12.5 Mesh Led Display

We are offering our customers excellent quality P12.5 Mesh LED Display which has the very good application to stages, bars, hotels, top grade restaurants and such indoor environment.

Ita s pieced and fitted together on option with easy installation and disassembly. It can show various videos, flashes and also various lighting effects made by professional lighting designers.

The popular sizes are P12.5/P16/P20.

Pixel pitch: 12.5mm
Pixel density: 6,400 dots/ m 2
Pixel Composition: SMD 1R 1G 1B
Size of cabinet: 800x400(LxW) mm
Cabinet resolution: 64 x 32(LxW) dots
Display weight: a 25Kg / m 2
Viewing angle: 120A /120A
Panel thickness: a 60 mm
Normal power consumption: 200W/ m 2
Driving mode: Static constant current driving
Frame frequency: 60 Hz
Refreshing frequency: a Y600 Hz
Gray Scale: a Y12bits/4096level
Brightness of white balance: a Y2500 cd/ m 2
Power supply: AC220V/50Hz (A 10%) or AC110V/50Hz (A 10%)
