Mtl4501-sr Fail Safe Switch

The MTL4501-SR is a single-channel fail-safe switch/proximity detector interface with Line Fault Detection (LFD). It provides intrinsic safety isolation between hazardous-area switches or proximity detectors and a fail-safe electronic output in the safe area.

The MTL4501-SR is designed for safety instrumented systems requiring operation up to SIL 3 according to IEC 61508. It is backplane mounted and is part of the MTL4500 series intrinsic safety isolators.

TECHNICAL DATA
Brand: MTL
Model: MTL4501-SR
Type: Fail-Safe Switch / Proximity Detector Interface
Channels: 1
Input: Switch / Proximity Detector
Output: Fail-Safe Solid-State Output
Output Voltage: 24 VDC nominal
Maximum Output Current: 25 mA
Line Fault Detection: LFD
Supply: 20AcA A 35 VDC
Mounting: Backplane
Safety Integrity: SIL 3
Hazardous Area: Zone 0, IIC / Div. 1
Function: Intrinsic Safety Isolation
FEATURES
Single-channel fail-safe interface
Switch and proximity detector compatibility
Line Fault Detection (LFD)
Fail-safe solid-state output
Intrinsic safety isolation
Suitable for SIL 3 safety applications
Backplane-mounted MTL4500 series module
Designed for hazardous-area industrial applications
