Manual Taping Machine - 2180mm X 700mm X 500mm | Adjustable Tape Width 8mm-72mm, Dual Pid Temperature Control, Fiber-optic Component Detection

Following are the Main Features of Manual Taping Machine :
1, Track width can work freely in the range of 8mm to 72mm,the screen is easy and convenient for operate and control.
2, Fine adjustment head installed in hot-press device, adjustment of sealing position can accurate to 0.1A mm,independent PID temperature control accurately and steadily.
3, The position of cover tape can make fine adjustment by adjust the tension of the moving cover tape.count by fiber-optical sensitive and equipped with leakage detection make braiding accurate.
4, Moving tape speed can be adjusted continuously and control by pedal, compatible with all ELA-481 standard plastic reels.
5, Pocket check function,Pocket Check serves to check automatically whether there is absence of components in the pocket and stop and prompt when absence of component is detected.


Specifications:
Size: 2180mm(L)*700mm(W)*500mm(H)
Feeding: suitable with ELA-481 standard wheel and cover tape
Tape width: 8mm-88mm
Power supply:AC200V,50Hz
Pressure: 3.0kg/cm2
Temperature control: two heads and independent PID temperature control,temperature range is 20-200
Taping speed: 3000-7000pcs/hr, According to specific component
Calculator: count by fiber-optical sensitive
Package type: self-adhesive or hot press
Weight: 70kg
