Linearised Temperature Indicator

Input : From 2 wire transmitter (4 to 20 mA), 24VDC available
Range : User selectable measuring ranges Programmable from -1999 to +1999, with decimal point. freely configurable from most to least significant digit.
Setting : Easy setting of measurement ranges & High/Low limits by Feather-touch, elegant, long life & user friendly membrane key pads.
No trimpots to be touched.
Display : Bright seven segment, 4 digits for parameter & 4 digits for status.
Limits : High & Low Limits
Controls : On-Off, TIme Proportional, PI control action
Dead Band : Programmable
Logic : Heater or Alarm Programmable
Output : 2 Relays corresponding to each limit rated 230 V / 6 Amp.
Retransmission O/P : User programmable 0-20mA/4-20mA, On request

Key Features :-
1. High accuracy linear temperature measurement within A 0.1A C or A 1A C.
2. Digital display with 4-digit LED for clear temperature readout.
3. Linearizes non-linear input from thermocouples and RTDs for precise readings.
4. Supports multiple sensor types including thermocouples (J, K, R, S, B, C, D) and RTD Pt-100.
5. Automatic cold junction compensation for thermocouples.
6. Single or dual set point temperature control with ON/OFF output.
7. Robust metal enclosure with powder coating and polycarbonate front.
8. Resistant to EMI/RFI interference due to digital design.
9. User-friendly operation with front panel thumb wheel adjustment.
10. Suitable for high temperature and industrial applications like furnaces, heat treatment, metallurgy, and ceramics.
