Leaf Filter Apparatus - Application: Mechanical Engineering Lab Equipment

Specification:
LEAF FILTER APPARATUS
Description:
Leaf filters, sometimes called tank filters, they consists of flat filtering elements (leaves) supported in a shell. The leaves are circular, arc-sided, or rectangular, and they have filtering surface on both faces. The shell is a cylindrical tank the set-up consists of flat filtering elements (leaves) supported in a slurry tank. A filter leaf consists of a perforated plate over which a filter medium of woven fabric is fitted. The whole assembly is connected to a vacuum pump through a filtrate receiver. An agitator is fitted in the slurry tank. Drain valve is provided in it. The set-up is operated batch wise.
Experimentation:
To determine the specific cake resistance for the given slurry using Leaf Filter
Product Specification
Usage/Application: Industrial
Automation Grade: Semi-Automatic
Agitator Material: IRON
Usage: FOR UNIVERSITY
Body Material: S.S
Floor Area: IRON
Finishing: NEW
Flow Rate: >4000 m3/hr
Valve Size: 3/4
Vessel Diameter: 400-600 mm
Vessel Height: 800-1000 mm
