Side Extensometer - Application: Concrete Testing Equipment
Price:
Get Latest Price
Minimum Order Quantity :
1 Unit
Brand Name :
Teknik
In Stock
Product Specifications
| Power Supply | Not required (operates mechanically) |
| Mounting Type | Mechanical clamp |
| Product Type | Lateral Extensometer |
| Usage | Concrete Testing Equipment |
| Display Type | Dial Gauge |
| Resolution | 0.01 mm |
| Response Time | Instantaneous (mechanical) |
| Application | Concrete Testing Equipment |
| Features | Precision adjustment, robust mechanism, easy attachment |
| Accuracy | A+-0.01 mm |
| Test Range | 0aEUR"5 mm |
| Number of Specimens | 1 |
| Hardness | Case hardened steel contact points |
| Temperature | 10AdegC to 50AdegC |
| Humidity | Up to 85% RH |
| Specimen Size | 150 mm x 150 mm (standard cube) |
| Equipment Type | Side Extensometer |
| Measuring Range | 0aEUR"5 mm |
| Automation Grade | Manual |
| Capacity | 0aEUR"5 mm displacement |
| Machine Weight | Approx. 1.5 kg |
| Test Speed | Manual |
| Test Width | Up to 150 mm |
| Test Stroke | 10 mm |
| Control Mode | Mechanical |
| Supply Ability | 100 Per Week |
| Delivery Time | 1 Week |
| Sample Available | Yes |
| Sample Policy | Sample costs shipping and taxes has to be paid by the buyer |
| Packaging Details | carton box, export quality also available |
| Main Export Market(s) | Middle East, Asia, Africa |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001 ,CE |
Product Overview
Key Features
The unit consists of two movable frames pivoted at one end. The extensometer is fixed to the specimen with the help of tightening screws. The lateral extension is indicated on a dial gauge which is mounted on the upper ring and the tip of the dial gauge rests on an anvil. The zero on the dial gauge can be set by adjusting the anvil screw.
TECHNICAL SPECIFICATION
The unit consists of two movable frames pivoted at one end.
The extensometer is fixed to the specimen with the help of tightening screws.
The lateral extension is indicated on a dial gauge of 0.002mm x 12mm travel.
The extension is magnified 2.5 times and the dial gauge readings are to be divided by 2.5 to get the exact readings.
A spacer strip is provided to initially set the dial gauge, and can be removed after initial setting.
Supplied in a wooden carrying case.
The lateral extensions of 15cms dia x 30cm high cement concrete
Cylinders while testing them under compression.
