Ctc Tea Dryer

Backed by advanced R&D, T&I Global Limited (TIGL) introduces the ultimate in vibratory fluid bed technology - the Everest drier. The heart of the Everest transport system is the revolutionary and logical drive mechanism, which ensures that the tea moves in a first-in first-out series. Everest is the latest TIGL drier, designed to produce Orthodox & CTC teas with bright tea and infusions, blacker appearances, better bloom and density.

Salient Features & Advantages:

Unique Vibro-Drive Mechanism : Ensures accurate adjustment of product drying timeVibratory Bed : Pneumatic system provides uniform spring action across the bedPlenum Chamber : The plenum chamber is aerodynamically designed, insulated and fabricated with steelDistributor Plates : Unique distribution plates ensure better fluidisation and less fall throughHot Air Fan :Aerofoil design ensures higher energy efficiencyDust Collection System : Includes Multi-clone re-firing arrangement designed for eliminating side spillages and for greater hygiene, cleanliness & energy efficiencyCentralised Operating ConsoleEfficient Inbuilt Ball Breaker & Full-width Feed ConveyorStainless Steel Contact Parts : Ensures better hygiene durabilityDischarge Cooler : For cooling dryer mouth tea (optional)Automatic Hood Pressure Control System :For uniform fluidization (optional)Low fuel and power consumption and negligible maintenance costsWide Range :Low fuel and power consumption and negligible maintenance costs Wide Range Everest is available in 3 models with different, capacities & sizesCustomised Models :Everest can be adapted to meet specific needs.Specifications:



body,div,table,thead,tbody,tfoot,tr,th,td,p { font-family:"Liberation Sans"; font-size:x-small }
a.comment-indicator:hover + comment { background:#ffd; position:absolute; display:block; border:1px solid black; padding:0.5em; }
a.comment-indicator { background:red; display:inline-block; border:1px solid black; width:0.5em; height:0.5em; }
comment { display:none; }









Unit
184 SFBD
244 SFBD
245 SFBD
305 SFVD
405 SFBD


Capacity at 70% dryer inlet moisture
**kg/hr
225
300
375
450
650


Capacity at 55% dryer inlet moisture
**kg/hr
425
575
650
850
1250


Length
m
10.3
12.5
12.5
14.2
17.2


Width
m
3.4
3.4
3.8
3.8
3.9


Height
m
4.9
4.9
4.9
4.9
4.6

** Depends upon drier inlet temperature, altitude, drying temperature and manufacturing method of the factory * 5 HP more needed when operating indirect heater to meet extra pressure drop in the heater Due to a continuous process of development the design and specifications are subject to change without noticeNote:-Due to a continuous process of development the design is subject to change without notice.
