Ir Remote Control For Electrical Appliance

Dimension: 45x100x150 (mm)
Weight: 400g
Color: white
Cabinet: PVC
Type: wall mountable/ table mountable
Availability: (4(ON/OFF) +1 (voltage control))-channel and 8(ON/OFF only)-channel
Warranty: 1-year manufacturer replacement warranty
Sensor characteristics:
a cWorking in day/night without change in accuracy
a cIR receiver range: 10-20 meters
a cVery low power consumption (less than 10mW)
a cImproved shielding against EMI
a cImproved immunity against ambient light
a cInsensitive to supply voltage ripple and noise
Applications:
a cIR Remote controlled Electrical Fan speed control
a cRemote controlled Fluorescent/ CFL/LED lamp ON/OFF
a cRemote controlled TV/Music system/ PC/ Radio ON/OFF
a cRemote controlled inverter/ UPS/ solar-UPS ON/OFF
a cRemote controlled Gate driving motor control ON/OFF
a cRemote controlled single phase 1Hp motor ON/OFF
a cRemote controlled Ac/ washing machine/refrigerator ON/OFF
Electrical parameter:
a cLow power consumption (less than 10 watts)
a cWide operating voltage (90-300 VAC)
a cInbuilt over voltage protection for processing unit
Appliance ratings: single phase
a cUpto 1hp induction motor without starter (single phase)
a c1Amp to 7Amp all electrical applications
Appliance Protections:
a cInbuilt over/under voltage protection
a cInbuilt over loadload protection with fuse
a cInbuilt surge/ voltage spike protection
Features:
a cAppliance status(on/off) LLED indication
a cFlash programming control with EEPROM
