Induction Heater 2004 - Bearing Weight 700/1200 Kg, Power 25/40 Kva, Voltage 440v | High Efficiency, Precise Controls, Easy Operation
Get Latest Price
In Stock
Product Specifications
| Bearing Diameter | 60-900 Mm |
| Bearing Weight | 700/1200 Kg |
| Features | Safe Process, High Efficiency, Precise Control, Easy Operation, High Heating, Lower Cost |
| Max Temperature | 400 C |
| Overall Dimension | 1000X580X850 |
| Power | 25/40 Kva |
| Temperature Range | 0-250 C |
| Voltage | 440 V |
| GSTIN | 0% |
Product Overview
Key Features
PRECISION Induction Heater model PIH 2004 has heavy capacity to heat the components. It has controls similar to PIH-2003, which are intelligent micro controller based electronic control
It weights about 300kg. It can heat a bearing of 700 kg to temperature as per requirement in customized time.
Model PIH 2004 is provided with manual or automated Roll-sliding Arrangement for the standard yoke 105 x 105 x 590 mm. The Roll-Sliding Arrangement is so designed that the yoke gets lifted mechanically or automatically rolls off from the vertical supports without rubbing or damaging and scraping mating surfaces. This arrangement provides additional safety, ease of operation and helps to improve productivity.
FEATURES:
- Can be used for Mounting 8. Dismounting of inner Race
- Safe, Reliable & Clean Process.
- Unskilled labour can be trained to operate.
- High Heating can be easily achieved.
- Lower cost 8. high efficiency.
- Precise Temperature and Time controls.
- Intelligent micro control based electronic controls
| PRODUCT DATA | PHI 2004 |
| Diameter (mm) Bearing | 60to900 |
| Bearing Weight | 700 / 1200 kg |
| Power | 25 / 40 kva |
| Voltage | 440 v |
| Power Control | 25%, 50%, 75%, & 100% |
| Temperature Control (Range) | 0-250ºC |
| Maximum Temperature | 400ºC |
| Accuracy Temperature | ±3ºC |
| Time Control | 0-99 Minutes |
| Residual Magnetism | <2A/cm |
| Overall Dimension (WxDxH)(mm) | 1000 x 580x 850 |
| Space between Supports (WxH)(mm) | 350 x 450 |
| Weight (Mian Unit) | 300 / 370 kg |
| Weight With Standard Yokes | 345 / 415 kg |
| Horizontal Yoke Size (mm) | 100x100x620 |
|
| - |
|
| - |
| Can Heat Sealed & Pre-greased Bearings | yes |
| Thermal Ovar Protection | yes |
| OPTIONAL ACCESSORIES | |
| Horizontal Yoke Size (mm) | 50x50x620 |
|
| 60x60x620 |
|
| 70x70x620 |
|
| 80x80x620 |
| Digital Thermometer (0-500ºc) | yes |
| Roll-Sliding Model | yes |
| Swing Arm Model | yes |
| Riser Block (pair)(mm) | - |
| Magnetic Temperature Prabe | yes |
| Equipment Trolley | yes |
