Impulse Voltage Test System - Fiberglass Stainless Steel Epoxy Resin, 3500x1400x2400 Mm, White/blue/red | 100-2000 Kv, 50 Kj Impulse, Microprocessor Control, Auto Polarity Reversal, Safety Interlocks

Get Latest Price

Minimum Order Quantity :

In Stock

Product Specifications

Usage & Applications	Used for high-voltage equipment, insulation material, and transformer impulse testing
Batteries Type	Not applicable (mains powered)
Pressure	Atmospheric (operational indoors)
Accuracy	Impulse peak accuracy 1.5%
Resistant Feature	High dielectric and mechanical strength, robust against electrical breakdowns
Product Type	Impulse Voltage Test System
Material	High-grade insulating fiberglass, stainless steel, and epoxy resin
Measuring Voltage Range	100 kV to 2000 kV (modularly extendable)
Operating Temperature	0C to 40C
Frequency (MHz)	Up to 1 MHz pulse repetition capability
Insulation Box	Available for high-voltage sections
Protection System	Over-voltage and over-current protection integrated
Size	Customizable as per testing requirements
Color	White/Blue/Red (standard industrial colors)
Dimension (LWH)	Approx. 3500 mm x 1400 mm x 2400 mm
Weight	Approx. 1500 kg (varies by configuration)
Payment Terms	Cash in Advance (CID)
Supply Ability	8 Per Month
Delivery Time	2-5 Days
Main Domestic Market	All India
