Igbt Characteristics & Application

Get Latest Price

Minimum Order Quantity :

1 Piece

Brand Name :

Teknik

In Stock

Product Specifications

Frequency	Up to 20 kHz typical, higher possible
Max Height	Varies as per module/package
Mounting Type	Module, Chassis Mount
Test Range	Collector-Emitter Voltage up to 1700V
Features	High Voltage & Current Handling, Fast Switching, Low Conductive Loss, Integrated Protection
Measuring Range	10A to 1200A depending on model
Equipment Type	Insulated Gate Bipolar Transistor (IGBT)
Number of Specimens	Single Device or Module
Temperature	Operating Junction -40C to 150C
Specimen Size	Depends on configuration
Interface Type	Discrete or Module
Humidity	Standard Operating Humidity
Usage	IGBT CHARACTERISTICS & APPLICATION
Automation Grade	Manual/Automatic depending on application
Product Type	IGBT CHARACTERISTICS & APPLICATION
Application	IGBT CHARACTERISTICS & APPLICATION
Operating Voltage	600V / 1200V / 1700V
Resolution	High (sub-volt, sub-amp)
Response Time	Fast switching (10ns to 200ns turn-on/turn-off time)
Accuracy	High switching accuracy
Power Supply	600V, 1200V, and 1700V available
Capacity	Ranged by Current Handling (e.g. 20A, 40A, 75A, 100A+)
Machine Weight	Varies depending on module size
Control Mode	Voltage & Current Controlled
Payment Terms	Cash Advance (CA), Cash in Advance (CID), Cheque, Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Letter of Credit (L/C)
Packaging Details	Carton Box, Export Quality also Available
Main Export Market(s)	Asia, Middle East, Africa
Main Domestic Market	All India
Certifications	ISO 9001, 14001, CE
