I Beam Conveyor By Alig Conveyor Automation Private Limited

Our organization holds expertise in manufacturing and supplying the finest quality I Beam Conveyor. These conveyors are manufactured using excellent quality raw materials procured from trusted sources of the industry. Moreover, our professionals make sure to check the quality of the entire range before delivering to the customers. To cater to the diverse requirements of customers, we offer these conveyors in variegated specifications and designs. Our I Beam Conveyor is applicable for various continuous materials handling work.

Features

• Highly functional
• Increased longevity
• High breaking strength


I- Beam Conveyor

TECHNICAL SPECIFICATION (I-348/458/678)

Chain Forged link rivetless chain

Size 348/458/678

Pintch 3",4" & 6"

Pin dia 3/8",4/8",7/8".

Breaking stength 8,000 kgs.,16,000 kgs.,32,000 kgs.

Allowable Pul 800 kgs.,1,600 kgs.,3,200 kgs.

Material EN8

Finish Shot blasted & bearing surface milled.

Trolley 2 wheel trolley with forged bractet. wheel are fitted with anitifricion ball bearings duly packed with provision for regressing

Track Made of IMSB 75,100, 150 mm

Bends All horizontal & vertical bends are porvided as per layout reuirement. Horizontal bends are provided with hardened guide rollers fitted with anti-friction ball bearings & sealed for life.

Drive Heavy duty sprocket . caterpiller type unit Fitted with moter & worm reduction gear box.

Oiler Airmist lubrication provided.

Take up Screw Type.
