High-medium Pressure Hydraulic Hose Assemblies - Synthetic Rubber With Rayon And High Tensile Steel Wire Reinforcement, Suitable For -40â°c To +100â°c Operating Temperature, Various Sizes From 3/16" Id To 4" Id
Price:
Get Latest Price
In Stock
Product Specifications
| Features | High pressure, Durable, Versatile, Reliable, Metal fittings, Temperature resistant, Various sizes |
| ID | 3/16"-4" |
| Reinforcement | Steel wire/Rayon |
| Standards | SAE100R1, SAE100R2, SAE100R3, SAE100R5, EN853, EN854 |
| Temperature Range | -40°C to +100°C |
| Tube Material | Synthetic rubber |
| Usage | Hydraulic systems; Construction; machinery; oil transfer |
| Working Pressure | 40-400 MPa |
Product Overview
Key Features
High-Medium Pressure Hydraulic Hose Assemblies PM & PH series
Synthetic rubber tube suitably reinforced with rayon and or high tensile steel wire, suitable for working temperature of -40C to + 100C and for high and medium pressure applications. The hoses are ideally suited for Petroleum based hydraulic fluids, diesel, Petrol and lubricating oils. Hoses are available from 3/16" ID (4.7 mm) to 4" ID (101.6 mm)
CEE DEE INDUSTRIES listed its name among the famous Manufacturers, Suppliers and Exporters of High-Medium Pressure Hydraulic Hose Assemblies. These products are widely used in various hydraulic equipment that transfer pressure coal transfer pressure coal construction machinery industry. Also, these assemblies are suitable for transporting hydraulic fluids like ethanol, hydraulic liquid, fuel oil, lubricating oil and emulsions, etc. Our provided High-Medium Pressure Hydraulic Hose Assemblies consists of metal joints and are combined into assemblies of various types. Below we have provided the specifications of this product:
Specification :
|
| ID INCH | 1/4" | 5/16" | 3/8" | 1/2" | 5/8" | 3/4" | 1" | 1 1/4" | 1 1/2" | 2" |
| ID MM | 6.4 | 8 | 9.5 | 12.7 | 16 | 19 | 25.4 | 31.8 | 38 | 50.8 |
| PM1-SAE100R1 EN853-1SN ONE WIRE REINFORCED | Working Pressure | 225 | 215 | 180 | 160 | 130 | 105 | 88 | 63 | 50 | 40 |
| Test Pressure | 450 | 430 | 360 | 320 | 260 | 210 | 176 | 126 | 100 | 80 | |
| BEND RADIUS | 100 | 105 | 130 | 180 | 200 | 240 | 300 | 420 | 500 | 630 | |
| Impulse Test: 150000 Cycles | |||||||||||
| PM3-SAE100R3 EN854-R3 TWO WIRE REINFORCED | Working Pressure | 86 | 83 | 78 | 69 | 60 | 52 | 39 | 26 | 17 | 15 |
| Test Pressure | 172 | 166 | 156 | 138 | 120 | 104 | 78 | 52 | 34 | 30 | |
| BEND RADIUS | 76 | 102 | 102 | 127 | 140 | 152 | 203 | 254 | 306 | 410 | |
| Impulse Test: 150000 Cycles | |||||||||||
| PM5-SAE100R5 WIRE RAYON REINFORCED | Working Pressure | 207 | 155 | 138 | 121 | 103 | 55 | 43 | 34 | 24 | 24 |
| Test Pressure | 414 | 210 | 276 | 242 | 206 | 110 | 86 | 68 | 48 | 48 | |
| BEND RADIUS | 66 | 102 | 117 | 140 | 165 | 187 | 229 | 267 | 337 | 61 |
| PH1-SAE100R2 EN853-2SN TWO WIRE REINFORCED | Working Pressure | 400 | 350 | 330 | 276 | 250 | 215 | 165 | 125 | 90 | 80 |
| Test Pressure | 800 | 700 | 660 | 552 | 500 | 330 | 330 | 250 | 180 | 160 | |
| BEND RADIUS | 100 | 115 | 130 | 180 | 200 | 240 | 300 | 420 | 500 | 630 | |
| Impulse Test: 150000 Cycles | |||||||||||
| PH2-2ST BCS-174 TWO WIRE REINFORCED | Working Pressure | 450 | XX | 380 | 362 | 280 | 276 | 215 | 172 | 146 | 112 |
| Test Pressure | 900 | XX | 760 | 724 | 560 | 552 | 430 | 344 | 292 | 224 | |
| BEND RADIUS | 100 | XX | 130 | 150 | 190 | 230 | 300 | 380 | 450 | 600 | |
| Impulse Test: 150000 Cycle | |||||||||||
| PH3 POWER EXCEEDS 2SN TWO WIRE REINFORCED | Working Pressure | 400 | 350 | 330 | 275 | 275 | 275 | 250 | XX | XX | XX |
| Test Pressure | 800 | 700 | 660 | 550 | 550 | 550 | 500 | XX | XX | XX | |
| BEND RADIUS | 50 | 55 | 60 | 90 | 100 | 150 | 200 | XX | XX | XX |
