Hydraulic Die Cutting Machine - 1300x900x1500mm, 3kw Power | High Efficiency With Automated Ejecting Units, Stable Performance, Accurate Pressure Adjustments

Price:

Get Latest Price

In Stock

Product Specifications

Cutting Pressure	12 T
Dimensions	13009001500 Mm
Effective Size	820*520 Mm
Features	Powerful Pressure, Accurate Cuts, Automated Ejecting, Auto Stop, High Efficiency, Stable Performance, Saves Labor, Saves Time
Material	Steel
Power	3 Kw
Pump Pressure	8 Mpa
Weight	1100 Kg

Product Overview

Key Features

Hydraulic Die Cutting Machine

With our rich experience in manufacturing, exporting and supplying of best quality Hydraulic Die Cutting Machine, we have managed to achieve a reputed position in the respective domain. The entire process of production is controlled by our talented team of employees ensuring each and every machine would be tested on various quality parameters. Only after going through all quality check, the final dispatch would take place. The main function of Hydraulic Die Cutting Machine is to cut the paper into desirable shapes. It is has some significant characteristics such as powerful die cutting pressure, accurate adjustments, fully automated ejecting units, can stop automatically and separating the paper from the die . In addition to this, has a supporting structure of four columns thus, results in high efficiency and stable performance which helps in saving labor and time.

Quick Details

Condition: New
Type: Die-cutting Machine
Place of Origin: Jiangsu, China (Mainland)
Brand Name: ZNEP
Model Number: ZNMQ-170
Voltage: As you required
Power(W): 3KW
Dimension(L*W*H): 1300*900*1500mm
Weight: 1100kg
Certification: CE
Warranty: 12 Monthes
After-sales Service Provided: Engineers available to service machinery overseas
Performance: Stable

Packaging & Delivery

Packaging Details:	export standard wooden cases, which is suitable for long-distance sea transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.
Delivery Detail:	30 working day

TECHNICAL PARAMETER:

ITEM	SPECIFICATION	UNIT
effectine running size for stand boare	820*520	mm
the pressure of die cutting	12	t
the pressure of oil pump	8	Mpa
total machine power	3	kw
machine weight	1100	kg
machine dimension	13009001500	mm
