Horizontal Flow Wrapper - Automatic Operation, 3600x1500x1800 Mm Dimensions, 1.5 H.p. Dc Drive, 1350 Kg Weight | High Sensitivity Optical Mark Tracking, Fault Self-diagnosis Function, Flexible Bag Length Cutting

Horizontal Flow Wrap Pil : -

Packing Products :

Pre Wrapped Biscuits (50, 75 & 100 gms), 4 Biscuit Naked pack, chocolate Bar, Soap Cakes, Washing Scrub, Bearings, Oil Seal, Cycle Tube, Auto Parts, Cassettes, Aggarbathi and any single item to be packed horizontally.

Details: Main functions and structural characteristics:

1. Controlled by double transducer, flexible bag length cutting, can be finished in one go so that operator needn't to adjust from time to time, saving time and film.
2. Human-machine interface, quick and convenient parameter setting.
3. Fault self-diagnosis function, failure can be clear at a glance.
4. High sensitivity optical electric color mark tracking, digital input cut position which makes the sealing and cutting more accurate
5. Separate PID control the temperature, suitable for various packing materials.
6. Stopping the machine in selected position, no sticking to the knife and no waste of packing film.
7. Simple driving system, reliable working, convenient maintenance.
8. All the controls are achieved by software, convenient for function adjusting and upgrading.

Specifications :

• Sealing Type - Center Seal
• Speed - 40-120 Pouches / Min
• Motor - 1.5 H.P.D.C. Drive
• Feeding Style - Automatic / Manual
• Power Load - 2 K.W. Single / Three Phase Heater 4 x 110W for Sealing Jaws, 2 x 110W for Center Sealing
• Weight - 1350 Kg. (Approx)
• Dimensions - 3600 (L) x 1500 (W) x 1800 (H) mm
