Highly Durable Playground Swings - Metal Construction, 3.2m X 1.5m Safe Play Area , Ideal For 6-12 Years With Enhanced Swing Mechanism

Backed by rich industry experiences, we are leading Manufacturer & Supplier Company of Highly Durable Playground Swings in Hyderabad, Telangana, India.
Descriptions
a c Product Area : 3.2m x 1.5m (10.5ft x 5ft)
a c Safe Play Area : 4.2m X 2.5m (13.8ft X 8.2ft)
a c Ideal For : 4-14 Years
a c Friends at a time : 2

Technical Specification:
a cArc swimg frame :6000mm long 80NB Pipe bent in Single Piece & welded together with a flange 5mm thick & ISA of 40x40x5mm to form a strong frame.
The 80NB pipe is hot dip galvanized pipe conforming to IS 1239 with GI thickness of 60I . Height of the frame is 2700mm.
a cTop pipe : 50NB Top Pipe with two Arc Swing Flanges welded at both its ends. Pipe can withstanding torsional stress created due to swinging motion. These
50NB top pipe is hot dip galvanized pipe of length 2950mm conforming to IS 1239 with GI thickness of 60I .
a cSeat assembly :
1) Swing clamp assembly :Swing clamps made up of two parts are joined together with M6 Allen bolts along with S-Hook & a specially designed
swing pin.The S-Hook is specially designed to house a bearing for smooth & noiseless swinging. The clamps are made
from injection molded Nylon-6 plastic.
2) Chain :Rubber dip molded swing chain of dia. 6mm & 1450mm Long.
3) Hook :S-Hook of dia 8mm & 145x130 Triangular hook of Grade SS 304.
4) Seat :Rubber Seat made by Natural Rubber with sufficient reinforcement.
a cPipe Materials or Class: Light Duty ('A' Class) & Medium Duty ('B' Class) Series of pipes only. Wall thickness of pipe varies according to class / series of
pipe used.
a cPowder coating : It shall be done with pure polyester raw material.Dry film Thickness
