Fluke Bt510 Basic Battery Analyzer With Basic Test Lead Set

Battery Resistance/Strap Resistance
Range -
3 mIC
30 mIC
300 mIC
3000 mIC
Resolution -
0.001 mIC
0.01 mIC
0.1 mIC
1 mIC
Accuracy -
1% + 8
0.8% + 6
V DC
Range -
6 V
60 V
600 V
Resolution -
0.001 V
0.01 V
0.1 V
Accuracy -
0.09% + 5
V AC (45 to 500 Hz with 800 Hz filter)
Range - 600 V
Resolution - 0.1 V
Accuracy - 2% + 10
Frequency
Range - 500 Hz
Resolution - 0.1 Hz
Accuracy - 0.5% + 8
AC Voltage Ripple (20 KHz Max)
Range - 600 mV
6000 mV
Resolution - 0.1 mV
1 mV
Accuracy - 3% + 20
3% + 10
General Specifications
Meter Mode - 999 records for each measurement position with time stamp
Sequence Mode - Up to 100 profiles and 100 profile templates (each profile stores up to 450 batteries) with time stamp
Temperature - Operating: 32 to 104A F (0 to 40A C)
Storage: -4 to 122A F (-20 to 50A C)
Battery charging: 32 to 104A F (0 to 40A C)
Operating Humidity - Non-condensing (50 A F [10A C])
a 80% RH (at 50 to 86A F [10 to 30A C])
a 75 % RH (at 86 to 104A F [30 to 40A C])
Altitude - Operating: Sea level to 2000 meters
Storage: Sea level to 12,000 meters
IP Rating - IP40
Radio - FCC Class A
Vibration Requirements - MIL-PRF-28800F: Class 2
Drop Test Requirements - 1 meter
Temperature Coefficients - Add 0.1 x specified accuracy for each A C above 28A C or below 18A C
Safety Compliance - 600 V CAT III
EMC - IEC 61326
Protection Class 2 - Pollution Degree II
Battery Compliance - UN38.3
UL2054
IEC62133
2G per IEC68-2-26, 25G, and 29
Screen Dimensions - 3 x 2.2" (7.7 x 5.6 cm)
Interface - USB mini
Dimensions - 9 x 4 x 2" (22 x 10.3 x 5.8 cm)
Weight - 1.9 lb (850 g)
