Fluidized Bed Micronizer Jet Mill

Fluidized Bed Micronizer Jet Mills are impact mills which are used to achieve maximum fineness values at maximum product purity. Such particle sizes can only be obtained in connection with an air classifying step. Spiral jet mills have a static air classifier integrated into the mill housing, whereas fluidised bed opposed jet mills are equipped with a dynamic deflector-wheel classifier.

The fineness is set as a function of the classifying wheel speed. All-important is a high product loading of the nozzle jets in order to achieve a high concentration of particles and thus high impact probabilities. The patented MegajetAR nozzles were developed with this in mind. They consist of four small nozzles which as a result of their close proximity generate an underpressure at their common centre, and thus draw particles from the fluidised bed direct into the centre of the nozzle jet. The product level in the machine is controlled by means of load cells or by monitoring the current loading of the classifier drive.

Single-/multi-wheel classifier head.
Monobloc ceramic classifying wheels ensure minimum wear when processing abrasive products .
Lining: PU, ceramic or special-grade steel to suit the product.
Stainless steel or mild steel, Ni alloy.
Horizontal or 3D nozzle arrangement, Megajet nozzles.
Selective milling, semi-batch mode, automatic quality control for high quality.
Load cells for product level control.
