Fire Class 100/200

The FIRE CLASS 100/200 is a programmable, modular control panel (EN54 Approved), suitable for small to medium fire alarm systems. It has 1 analogue loop for the connection of fine control devices (sensors, alarm, buttons, sirens, etc), and a conventional controlled line. During the programming phase each loop device can be assigned to 4 of the 16 available software zones, these in turn, may be assigned to the 13 controlled and silenceable outputs (relays), managed by the control panel (1 on the main board and 12 on the 2 FC200/6OUT output expanders, optional). A fault output relay non-controlled and non-silenceable is also provided.
Up to 8 FC200/REP annunciator panels (optional) with the same display and fast key functions as the main panel, can be connected to the control panel by 2 wires, using an RS485.
It is possible to program and manage the control panel from a PC via the FC200/SW software application (optional). The telephone features are supplied by the FC200/COM telecom module.
Power Supply : 2.5 A switching supply/battery charger.

General Features :-
* EN54 Approved.
* 1 analogue loop : supports up to 99 analogue sensors and 99 modules.
* Automatic device-drift compensation.
* 1 conventional input line accepts up to 30 fire detectors and fire alarm buttons.
* 16 completely programmable software zones.
* 1 "C" alarm output.
* 1 controlled and silenceable alarm output (relay), completely programmable and expandable to 13, by means of FC200/6OUT expander modules.
