Fieldbus Junction Box

Under The Assistance Of Our Professionals, We Are Engaged In Manufacturing, Exporting And Supplying A Wide Spread Of Fieldbus Junction Box In Bengaluru, Karnataka, India.

Instruments In Zone 0...1/Div. 1
Trunk And Spurs Intrinsically Safe
For Foundation Fieldbus H1 And Profibus Pa
Supports Fisco And Entity

General Specifications:
Design / MountingOutside Installation
Fieldbus Interface
Main Cable (Trunk)
ConnectionInput (Trunk In): Terminals 1+, 2-, 3S
Output (Trunk Out): Terminals 4+, 5-, 6S
Rated VoltageMax. 35 V Dc
Rated Current3 A Dc
Outputs
ConnectionSpur 1: Terminals 10+, 11-, 12S
Spur 2: Terminals 13+, 14-, 15S
Spur 3: Terminals 16+, 17-, 18S
Spur 4: Terminals 19+, 20-, 21S
Spur 5: Terminals 22+, 23-, 24S
Spur 6: Terminals 25+, 26-, 27S
Spur 7: Terminals 28+, 29-, 30S
Spur 8: Terminals 31+, 32-, 33S
Rated VoltageSee Main Cable
Rated CurrentSee Main Cable
Directive Conformity
Electromagnetic Compatibility
Directive 2004/108/EcEn 61326-1:2006
Standard Conformity
Electromagnetic CompatibilityNamur Ne 21, En 61326
Degree Of ProtectionIec/En 60529
Fieldbus StandardIec 61158-2
Climatic ConditionsDin Iec 721
Ambient Conditions
Ambient TemperatureSee Table
Storage Temperature-40 ... 85 C (-40 ... 185 F)
Mechanical Specifications
Connection Type
Main Cable (Trunk)Terminals
Core Cross-SectionUp To 2.5 Mm2
Cable Diameter
Main Cable (Trunk)5 ... 10 Mm
Housing258 Mm X 114 Mm X 84 Mm (Without Cable Glands)
Degree Of ProtectionIp67
