Fabric Inspection Machine By Changshu Penglong Machinery Co., Ltd

These Fabric Inspection Machine is specially designed for inspecting and rolling up all kinds of knitted, printed, cotton, tricot, and woven fabrics etc.
Characteristics of Fabric Inspection Machine :
1. Photoeclectric hydraulic edge-alignment system amde in Taiwen is adopted. Power 1/2 HP
2. Fabric tension is adjustalbe via inverters, no shrink of fabric width.
3. Equipped with an spiral expanding roller to eliminate curled edge. Expanding power 1/2 hp
4. Speed of main motor is managed by two inverters. Power 1/2 HP
5. Digital counter could make accurate measurement of length in yards or meters which can be interchanged
6. Winding roller and feeding roller are driven by gear motor. Power 1 HPX 2sets
7. Imported special foamed winding roller dcould roll up warp and weft knitted plush and short floss without sliding movement and untidy edge. Fabric rolls are nerther too tight nor too loose.

Technical Parameters:
Fabric Width : 1800mm~3600mm
Max. Diameter of Fabric Rolls : 600mm
Highest Speed: 80m/min
Power of Main Motor :1HPA 2
Accuracy of Alignment :A 3mm
Dimensions : 2200mm(L)*2300mm(W)*1900mm(H) (1800mm)
