Electromagnetic Crack Detection Machine

We manufacture a precision engineered range of Coil Type Electromagnetic Crack Detection Machine/System that are available in various models for various purposes. These are classified in to two categories: Portable: * Divided in to two group namely mobile and portable * Consists of popular model MGPT 1000MK3 -a 1000 ampere AC/HWDC Machine with high current cables & prods * Ideal for inspection of large castings & welding * Hand held yoke is another member of this category meant for applications like pipeline inspection etc. * Machines with an output of 2000-10000 amperes constitute the mobile category * Such machines mounted on heavy-duty wheels and can undergo limited movement Stationery: * Sub-divided into two categories yoke type and coil type * Yoke type machines house the longitudinal magnetizing coils in two jaws, provided for clamping of the component * Such machines recommended for components having length up to 600 mm * For longer components, coil field machines are recommended as they can generate stronger magnetic folds over a length Specifications: * Current ranges up to 10000 Amps HWDC or AC * Job admit lengths from 500mm to 4000mm * Two power pack system for two magnetic fields * Combined Magnetization using two Magnetic field
