Laboratory Drying Oven - Inside Ss 304 With Mirror Polish, Outside Mild Steel Powder Coated | User-friendly Adjustable Stainless Steel Rod Trays, Forced Air Draft System

a TEMPOa make lab drying TI a 126 series ovens with forced air draft provided by means of blower fitted at the bottom of the oven. There is no rea circulation of air.

Temperature range - 50A C to 250A C
Temperature accuracy - A 0.5A C
Supply - 230V, AC

Construction
Ovens are made of double walled construction. The unit is insulated with 3a thick high grade glass wool insulation. The single door is fitted on heavy duty hinges. The unit is provided user friendly adjustable stainless steel rod trays.

Technical Specification
Controlling System
Microprocessors based auto tune PID temperature controller with a dual display of set value & process value for precise control of temperature with PT 100 sensor is used for temperature.

Air Circulation
Forced air draft is provided by means of blower fitted at the bottom of the oven (there is no rea circulation of air).

Heating System
Heating element made from the best quality wire are used on refractory supports.

Features
Additional safety thermostat to cut off heater supply in case temperature of overshoot. The single door fitted on heavy hinges. Specially designed stainless steel rod trays to ensure uniform temperature distribution.

Optional Features
CFR 21 part 11 compliance software for data logger
Data logger
Data scanner complete with sensor
Safety digital temperature controller
Timer

Standard Models
Inside SS 304 with mirror polish & outside mild steel powder coated.

GMP Models
Inside SS 316 with mirror polish & outside stainless steel 304 with the dull buff finish.
