Diesel Engine Middle Open Double-suction Fire Pump Set

The diesel fire pump is composed of a diesel engine and a
fire pump. The pump set is a horizontal, double-suction, single-stage
centrifugal fire pump. It has the characteristics of high efficiency, wide
performance range, safe and stable operation, low noise, long service life,
convenient installation and maintenance, etc. Therefore, the diesel engine pump
unit is used for conveying clean water or other liquids with physical and
chemical properties similar to water. It can also be used to transport hot water,
oil, corrosive or abrasive media by changing the material of pump flow parts,
sealing form and increasing the cooling system.

II. Technical
Parameters of Double-Suction Fire Pump Set with Middle Opening of Diesel Engine

Model: KL-KD

Brief introduction: inlet and outlet diameter, flow 50 ~
6000m3/H, lift 8-200m

Structure: mobile, fixed, containerized

Diesel engine speed: 960-3000r/min

Main application: fire fighting system, industrial water
supply system, hot water circulation, etc.

III. Working Principle of Double-Suction Fire Pump Set of
Diesel Engine

The inlet and outlet are all on the pump body. During maintenance, only the
pump cover needs to be lifted out, and the rotor parts can be moved for
maintenance without disassembling the pipeline. The diesel engine can be
arranged at the left end or the right end according to requirements, so that
the on-site installation is convenient. The axial dimension of the rotor part
is structurally shortened, the rigidity of the shaft is good, and the operation
is more stable and reliable. The pump body seal ring is provided, while the
impeller seal ring is optional.

IV. Advantages and
Characteristics of Double-Suction Fire Pump Set in Diesel Engine

1. Automatic start: the diesel water pump unit can automatically start and
put into full load operation within 5 seconds after receiving fire alarm/pipe
network pressure/power failure/or other start signals;

2.
Automatic charging: The storage battery can be automatically charged by the
mains supply or the diesel engine charging motor to ensure the smooth start of
the unit;

3.
Automatic alarm: automatic alarm protection for low oil pressure, high water
temperature and other faults of diesel engine, alarm and shutdown in case of
overspeed;

4.
Automatic preheating: keep the diesel engine in a hot standby state to ensure
emergency work;

5.
Direct-connected type: The diesel water pump unit below 360kw adopts the
technology of direct connection between the diesel engine and the water pump
through the elastic coupling, which reduces the fault points, greatly shortens
the starting time of the unit, and increases the reliability and emergency
performance of the unit;

6,
the user can also request to set other alarm output (non-standard supply);

7,
with telemetry, remote signaling, remote control functions (non-standard
supply).

V. Structure and Size of Double-Suction Fire Pump Set of Diesel
Engine
