Dial Snap Gauge - Aluminum Frame, Range 0-300 Mm | Precision Measuring Tool With Carbide Anvils, Insulated Grip, And Adjustable Stopper

We are offering our customers a huge range of Dial Snap Gauge. External Diameter Checking. It is a convenient instrument used for checking mass produced components with speed & precision.

Applications:
* External Diameter Checking
* Dial Snap Gauge is a convenient instrument used for checking mass produced components with speed & precision.

Features:
* Aluminum frame with plastic handle to provide insulation and firm grip.
* Ground and lapped carbide measuring anvils provide high wear resistance and long life. Chamfered anvils ensure easy & safe insertion of the work piece.
* Collet clamping of sensing device like dial indicators (mechanical or electronic) with 8 mm mounting shank ensures positive clamping and alignment to measuring axis.
* Smooth and anti rotational movement of the measuring spindle by guide pin.
* Adjustable stopper for correct positioning of work piece ensures accuracy in repetitive measurements.
* Protector provided to ensure adequate protection to the sensing device.
* Cylindrical setting master available on request
* Conforms to IS 14271-1995.
Range in mm
0-25, 25-50, 50-75 , 75-100,100-125,125-150,150-175, 175-200, 200-225,225-250,250-275,275-300
