Detergent Bar Wrapping Machine By B.r. Pouch Packing Machines Pvt. Ltd.

Our organization is vastly engaged in manufacturing, exporting and supplying a wide gamut of Detergent Bar Wrapping Machine in Noida, Uttar Pradesh, India. It offers a good mix of precision, reliability and repeatability with low maintenance, FINSEAL 11 SOAP gives cost effective packaging solution. Built to the highest standards, FINSEAL 11 SOAP maximizes process productivity for those companies seeking long term performance.

Highlights:-
Specially designed for wrapping toilet soap (Regular and guest size).
Laundry soap and detergent bars.
Link up of machine to plodder/stampping machine possible.
Individual packs or chain packs.
Two or more soaps can also be inserted in one pack (depending on size).
Autofeeder is an integral part of the machine.

Principle of Operation

Soaps are placed on flat belt conveyor, either by link up conveyor (not a part of the of the machine) or manually. These soaps are transferred to the infeed lug conveyor of the machine. Infeed conveyor then transfers soap into wrapping film that has been formed into a tube by means of forming folder. Bottom seal is made by three sets of rollers. Cross sealing and cutting knife separate the packed soaps. Heat sealable material like BOPP or laminates is used.

Standard Features

All surfaces over which soaps are transported are made of stainless steel Flat belt conveyor infeed with Transfer Unit Long seal is formed by means of three pairs of rollers, axes of which can be tilted to get best results Torque slip clutch to prevent damage in case of accidental jams Low voltage heaters for safety Individual temperature controls for heaters Print registration unit for printed wrapper Heavy distortion-free cast structure.

Optional Features:-
Date Printing unit.
Variable speed drive (AC frequency control).
Castors for mobility of machine.

Specifications:-
Product Size (all dimensions in mm)
L MAX 140W MAX 65H MAX 60
L MIN 40W MIN 25H MIN 5
All minimum and maximum sizes are not valid at same time. Other dimensions
