Crystal Oscillator - 172.5mm X 128.5mm Breadboard With 1685 Tie Points | Variable Pulsar Generator 1hz To 1mhz, Dual Push Switches, 16 Toggle Data Switches
Get Latest Price
Minimum Order Quantity :
1 Piece
Brand Name :
Teknik
In Stock
Product Specifications
| Interface Type | Standard PCB mounting (DIP/SMD) |
| Product Type | CRYSTAL OSCILLATOR |
| Mounting Type | Through Hole / SMD |
| Response Time | <1ms |
| Features | Hermetically sealed, low aging, high precision |
| Max Height | 3.7mm (typical for DIP-14) |
| Usage | CRYSTAL OSCILLATOR |
| Measuring Range | Frequency range: 1MHz to 70MHz (typical, varies by model) |
| Automation Grade | Manual installation |
| Specimen Size | Approx. 11.5mm x 4.7mm x 3.7mm (DIP-14); varies by type |
| Operating Voltage | 3.3V / 5V (model dependent) |
| Humidity | 0% to 85% RH (non-condensing) |
| Accuracy | A+-20ppm to A+-50ppm (at 25AdegC) |
| Resolution | Frequency stability up to 0.1ppm (varies by type) |
| Power Supply | 3.3V/5V DC (specific to model) |
| Port Size | Standard DIP or SMD package |
| Equipment Type | Electronic frequency reference |
| Temperature | -20AdegC to +70AdegC (operating) |
| Number of Specimens | Single oscillator per package |
| Frequency | Common: 4MHz, 8MHz, 12MHz, 16MHz, 20MHz, 24MHz, 32.768kHz, customer request |
| Application | CRYSTAL OSCILLATOR |
| Machine Weight | Approx. 3g to 8g (depending on series) |
| Control Mode | Fixed-frequency operation |
| Packaging Details | Carton Box, Export Quality also Available |
| Main Export Market(s) | Asia, Middle East, Africa |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001, CE |
Product Overview
Key Features
Size of Breadboard: 172.5 mm x 128.5 mm
Tie Points on Breadboard: 1685 nos (solder less)
DC Power Supplies: +5V, 1A; -5V, 500 mA (fixed)
+3V to +15V, 500 mA (variable)
-3V to -15V, 500 mA (variable)
Pulsar Generator: 1Hz to 1MHz in 6 steps (Variable in between the steps)
Amplitude : +3V to +15V (CMOS), 5V (TTL)
Duty Cycle: 50 %, output
Pulsar Switches: 2 nos (Push to On)
Data Switches: 16 nos (Toggle switches) (TTL/CMOS output)
