Counter-attacking Crusher

The Counter-Attacking Crusher absorbs the domestic and foreign advanced technology. The hard rock whose granularity is less than 60-300mm can be processed. The granularity of 80% finished products is less than 30mm. The output of product is shaped as cube. The crusher is the first choice to make aggregates for high level road and hydraulic electricity industry. The key feature are large crusher ratio, High crusher efficiency; Easy maintenance; Low operation expense.

Working Principle:
When the hard rock counter-attacking crusher works, the electric motor drives the rotor where installed hammers to rotate with high speed. When the materials get into the area which the hammers can be effective, under the impact function of the hammers at a high speed, the materials are thrown to the impact device above the rotor continuously. And then the materials are rebounded from the impact liner to the area where the hammers can be effective to be crushed again. The materialsa size from big to small all will be crushed in the impact chamber repeatedly. The process wona t stop till the material are crushed to the required size and then will be discharged from outlet.

Features:
Large crushing ratio
High crushing efficiency
Easy maintenance
Low operational expense
