Conveyor Safety Switch - Cast Aluminum Enclosure, Ip65, Rope Operated Emergency Stop, Belt Sway Protection, Weatherproof Manual Reset

Being into the business of manufacturing, exporting and supplying, we have been able to manufacture, export and supply our valued clients with a wide range of Conveyor Safety Switch in Pune, Maharashtra, India. It is a rope operated emergency SWITCH. It is provided with cast aluminium (LM 6) enclosure operating handle fitted with spring steel rings at both ends for fixing the rope. Pull cord switch is mounted on the walkway side of conveyer belt, preferably at about every 20 meters length. Rope is tied to the end rings of the handle. When the rope is pulled from any side, the switch is operated. The switch in the operated condition until and unless it is manually brought to normal position. BELT- SWAY SWITCH: This switch allows smooth running of the conveyer and protects it from damages by over swaying which can occur due to uneven loading of material, worn out idler roller bearings etc. The belt sway is generally mounted on both sides and near the edge of conveyer belt. A small gap is provided between contact roller and the belt edge to allow normal running of the belt with acceptable tolerance. When swaying exceeds normal limit, the belt edge pushes the contact roller, which drives the switch and operates the contact. This switch resets automatically when the belt resumes normal running. Both the above switches are housed in dust and weatherproof cast aluminium enclosure with IP55 / IP 65 grade of protection.
