Zuden Zd1000 Series Conventional Fire Alarm Control Panel - 4, 8, Or 16 Zones, Supports Up To 25 Devices Per Zone, Integrated Notification Appliance Circuits

Conventional Fire Alarm Control Panel: The reliable ZD1000 Series Panel is an easy to install and user friendly panel, available in 4, 8 or 16 zones and each zone is capable of holding up to 25 devices on each zone. The ZUDEN ZD1000 series uses conventional input devices, the panel accepts water flow devices, two-wire smoke detectors, four-wire smoke detectors, pull stations and other normally-open contact devices. Outputs include four Notification Appliance Circuits (NAC, SOUND1-4), three standard Form-A relays (alarm, trouble and supervisory) and an EIA-485 port to interface with remote annunciators and optional remote relay modules. The FACP is field programmable via the panel keypad. It also supervises all wiring, AC voltage and battery level.

ZUDEN ZD1000 series l is a highly cost-effective fire alarm controller, can constitute small-sized automatic fire alarm system, applicable to the hotel, residential, hospitals, industrial plants, entertainment locations, and other industrial and civil buildings.
