Cnc Auto-feeding Single Head Saw Machine

Primarily used for cutting aluminum profiles and PVC profiles for aluminum doors and windows, curtain walls etc.
1.Adopt 20 hard alloy saw blade and auto-spray lubricating and cooling system, ensures high cutting linear velocity and high surface finish quality and high accuracy.
2.Adopt Hydro-pneumatic damper stepless speed governing system, ensures smooth feeding.
3.Adopt AC servo motor, ball screws, and inlet guide bar for the machine and with digital display system and automation controlling system. It ensures high repositioning accuracy as well as A 0.05mm
Manual, automatic operation, and to carry out 45A Cutting.
Adopt colored man-machine touch-sensitive screen control, the interface is clear and easy to operate.
Adopt the imported integrated PLC control, with the self-measuring and self-diagnosing function. The circuit is of high stability and nice environmental applicability and can upgrading by long distance operation through net-works.

Main Technique Parameter:
1.Cutting length of automatically feeding:10~970mm
2.Cutting widthA Cutting height:215A 150 mm/ 240A 135 mm
3.Swing angle of saw blade:0A ~45A
4.Max Auto-feeding speed:10m/min
5.Power of main motor:2.2KW
6.Speed of main motor:2840r/min
7.Saw blade size: 500A 30A 120T
8.Saw blade feeding speed:0~3m/min
9.Saw blade returning speed:2~3m/min
10.Working pressure:0.6~0.8MPa
11.Working voltage:380VAC
12.Overall dimension : LA WA Hi :5000A 1200A 1300 mm
13.Weight:1500kg
