Cmos Ic Characteristics Apparatus - Dual Dc Power Supply +12v, +5v & Variable Outputs 0 To +12v, 0 To +5v, Pulse Generator 100khz | Ideal For Testing Cmos Ic Characteristics
Get Latest Price
Minimum Order Quantity :
1 Piece
Brand Name :
Teknik
In Stock
Product Specifications
| Features | IC under test short circuit protection, indicator LEDs for outputs, adjustable supply |
| Frequency | 50 Hz |
| Specimen Size | 14-pin, 16-pin DIP supported |
| Automation Grade | Semi-Automatic |
| Mounting Type | Portable, desktop |
| Measuring Range | 0-15V, 0-20mA (LED indication) |
| Temperature | 0AdegC to 50AdegC (operating) |
| Product Type | CMOS IC CHARACTERISTICS APPARATUS |
| Accuracy | A+-1% FSD |
| Application | CMOS IC CHARACTERISTICS APPARATUS |
| Response Time | Instant |
| Equipment Type | Trainer/Testing Apparatus |
| Display Type | 3 digit 7-segment LED |
| Test Range | Up to Supply voltage (0-15V adjustable) |
| Port Size | Standard IC socket (DIP) |
| Resolution | 0.01V |
| Interface Type | Front panel test points, IC Socket |
| Number of Specimens | Single IC under test |
| Power Supply | 230V AC A+-10%, 50 Hz |
| Operating Voltage | 230V AC |
| Humidity | 35% to 85% RH (operation) |
| Usage | CMOS IC CHARACTERISTICS APPARATUS |
| Machine Weight | Approx. 3.5 kg |
| Test Speed | Manual variable |
| Test Width | Standard: Single channel test socket |
| Control Mode | Manual and auto-test selection |
| Payment Terms | Cash Advance (CA), Cash in Advance (CID), Cheque, Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Letter of Credit (L/C) |
| Packaging Details | Carton Box, Export Quality also Available |
| Main Domestic Market | All India |
| Certifications | ISO 9001, 14001, CE |
Product Overview
Key Features
DC power supply : +12V, +5V
Variable
DC power supply : 0 to +12V
0 to +5V
Pulse Generator
Frequency : 100kHz 15%
Company Details
Business Type
Exporter, Manufacturer, Distributor, Supplier, Trading Company
Employee Count
25
Establishment
1973
Working Days
Monday To Saturday
GST NO
06ACMPJ7244B1ZS
Certification
ISO 9001 : 2015
