Chnspec Gloss Meter
Price:
Get Latest Price
In Stock
Product Specifications
| Battery | 3000mAh |
| Connectivity | USB, Bluetooth |
| Features | High precision, Durable, Easy use, Large battery, Multiple angles, Fast testing |
| Model | CS-380 |
| Repeatability | 0.2% |
| Resolution | 0.1GU |
| Size | 165x51x77 mm |
| Test Angles | 20, 60, 85 |
| Test Range (60°) | 0-1000GU |
| Usage | Paint, plastic, print, metal, ceramic, building material, leather gloss measurement |
| Weight | 400g |
| Packaging Details | Instrument, 5V/2A charger, USB cable, operating manual, software CD, calibration boards, metrology accreditation certification |
| Certifications | Authorized American PatentPatent No. US9243953B1, SPECTROPHOTOMETRIC COLORIMETER BASED ON LED LIGHT SOURCE AND METHOD FOR REALIZING THE SAME.Authorized Chinese Invention Patents1.Patent No. ZL 26.2, Color measuring instrument with double light source and compatible with SCI/SCE test condition.2.Patent No. ZL 60.1, Color measurement instrument based on D/8 condition for error correction of optical trap.3.Patent No. ZL 78.9, Handheld light source color illumination measurement instrument designed with optimized cosine response.4.Patent No. ZL 55.8, Light source color illumination measurement instrument designed with optimized calibration algorithm.5.Patent No. ZL 4.7,Photoelectric integral color measuring instrument based on composite LED light source and its measuring method.6. Patent No. ZL 25.2,Spectrum super resolution method for hand-held light source color intensity measuring instrument.7.Patent No. ZL 07.3,A spectrophotometer based on LED light source and its realization method.8.Patent No. ZL 57.1,A spectrophotometer that corrects SCI error based on D/8 condition.9.Patent No. ZL 85.3,Color measuring instrument for measuring object color using linear variable filter.10.Patent No. ZL 16.5,Method and apparatus for super-resolution microscopy based on fluorescenc emission suppression.11.Patent No. 03.8,A repetitivity optimization method of double light path device of spectrophotometer and optimization method, under review.12.Patent No. 78.6, Spectrophotometer using wavelength optimization and correction. |
Product Overview
Key Features
Gloss meter is also named gloss gauge or mirror gloss meter. It is mainly used for paint, plastic, print, metal, ceramic, building material, leather and other industries which need measure gloss. Gloss meter can be separated into two type single angle and triple angles (triple angles gloss meter is called multi-angles gloss meter). 2 model number is CS-300 (single angle) and CS-380 (triple angles).
Super Stability (Patent Right No.: ZL876)
Comfortable Grab Feeling
The shell is made by Dow Corning TiSLV material, a desirable elastic material. It is resistant to UV and bacteria and do not cause allergy. This design is for better user experience
Large Battery Capacity:
We fully utilized every space of the device and specially custom made advanced high density lithium battery in 3000mAH , which ensures continuous testing for 54300 times.
Model : CS-380
Test Angle : 20A ,60A ,85A
Test light spot(mm) :
20A :10*10
60A :9*15
85A :5*38
Test range :
20A :0-2000GU
60A :0-1000GU
85A :0-160GU
Resolution : 0.1GU
Test modes : Simple mode, standard mode and sample testing mode
Repeatability : 0-100GU:0.2GU
100-2000GU:0.2%GU
Test time : Less than 1s
Data storage : 100 standard samples; 10000 test samples
Size(mm) : 165*51*77 (L*W*H)
Weight : About 400g
Battery capacity : 3000mAh lithium battery
Port : USB, Bluetooth (optional)
