Bottle Leak Testing Machine - 200mm X 1200mm Conveyor Size, 50ml To 6l Volume Range | High Functionality, Accurate Pressure Measurement, Compact Design

Bottle Leak Testing Machine

Product Code-ME-02

Offering a wide range of Bottle Leak Testing Machine in different specification to meet the diverse requirement of client. These are made from high quality raw material. Designed and developed by our authorized vendors, these products are in compliance with the prescribed industrial norms.

Features:

• High functionality
• Durable
• Reliable

• Detects micro holes with great repeatability
• Stores up to 10 different parameter settings and are adjustable during testing
• Easy height regulation with one hand wheel
• Reflector less photocell for very quick & exact positioning
• Festo & Imported make valves & cylinder
• Imported Pressure Sensor for accurate & consistent measurement
• Our own custom built controller with a 2 x 16 character LCD display
• Integrated 5 digit pass and fail counters
• Variable speed drive with linear acceleration/deceleration adjustment
• Typically able to test most bottles for a 0.17 mm hole of less than 0.25 liters at up to 3000 per hour, 0.5 -1 Liters at 1200-1400per hour, 2.0 liters at 1000-1200 per hour and 5 liters at 450-600 per hour
• Test resolution to 0.1 mbar (0.01 kpa)

• Supply voltages 230 Vac / 5A single phase
• Orientation of conveyor form Left to Right
• Size of Conveyor : 200mm x 1200 mm long
• Height of Conveyor : 950-1100 mm range
• Volume of Containers: 50 ml - 6Ltrs
• Working air pressure 5 kg/ cm 2
• Max. input air pressure 9 kg/ cm2
• Weight 130 kgs.
• Max Container size: 450 mm high, 300 mm long, 150 mm wide, neck up to 45 mm with standard head.
• Bottle Leak Testing Machine is a hot product of our big firm.
