Bose Powershare Ps604d Adaptable Power Amplifier

Power: 500 W
Number of channels: 4
Impedance: 4 ohm
Noise level (SNR): 60 dB
Connectivity: USB
Color: black
Weight: 7.9 kg

Amplification
Channel separation (crosstalk): > 85 dB at 1 kHz, > 65 dB at 20 kHz
Dynamic range: 100 dB at rated power, A-weighted
Frequency response: 20 Hz a 20 kHz (A 0.5 dB) at 1 W
Gain (high-impedance): 35 dB (70V mode), 38 dB (100V mode)
Gain (low-impedance): 32 dB
Maximum peak power (asymmetrical): 1200 W
Maximum peak power (symmetrical): 300 W
Number of channels: 4
Rated power (asymmetrical): 600 W
Rated power (symmetrical): 150 W
SNR: 100 dB (at rated power, A-weighted)
THD+N: < 0.04% at 1 kHz, 4a 8 IC, 70V/100V

Audio inputs (analog)
Channels: 4 balanced, line
Connectors: (1) 12-pin Euroblock
Input impedance: 20 kIC
Maximum input level: 20 dBu at 12 dBu sensitivity
Sensitivity: 4 dBu (low), 12 dBu (high)

Audio inputs/outputs (digital)
Channels: 4 Dante in
Connectors: (2) RJ-45 Dante in/thru
Type: 12-pin Euroblock

Audio outputs (analog)
Channels: 4
Connectors: (1) 8-pin inverted Euroblock

Compliance
EMC: meets EN55103-2 immunity requirements for E2 electromagnetic environment

Electrical
Current draw (idle): 0.1 A at 120 VAC, 60 Hz / 0.06 A at 230 VAC, 50 Hz
Current draw (inrush): 8.0 A at 120 VAC, 60 Hz / 14.1 A at 230 VAC, 50 Hz
Mains connector: IEC C14 inlet
Mains voltage: 100a 240 VAC (A 10%), 50/60 Hz
Protections: high temperature, output short circuit, extra high frequency, excessively low/high AC line voltage
Power consumption: 14 W standby, 700 W maximum

General
Computer interface connection: RJ-45 (Ethernet, 100 Mbps)
Software applications: Control Space Designer 5.4 or later (Windows)

Indicators and controls
Controls (front panel): (1) power button
Controls (rear panel): output attenuators, mute contact
LED status indicators: (1) power/status LED, (4) input signal LEDs, (4) output limit LEDs
