Binocular Microscope

Binocular Microscope

Get Latest Price

Brand Name :

Sb

In Stock

In Stock

Product Specifications

FeaturesAnti-fungal coating, 360Adeg rotatable head, robust metallic body
Focus SystemCoarse and fine coaxial adjustment
View HeadBinocular head, inclined and rotatable
Spare PartsEyepiece, objectives, mirror, lamp
TheoryOther, Optical microscope for biological and laboratory analysis
DrawtubeBinocular
SensorNot Applicable (Optical)
ResolutionDependent on eyepiece and objective combination
InterfaceMechanical adjustment knobs
Focal DistanceAdjustable with coarse and fine focus
Magnification40x, 100x, 400x, 1000x (using standard objectives and eyepieces)
DimensionsApprox. 370mm x 135mm x 180mm (H x W x D)
Focus RangeCoarse and fine adjustment, typically up to 25mm
EyepiecesWidefield 10x Pair
Eyepiece TubeInclined, 360Adeg rotatable
IlluminationReflective mirror and sub-stage lamp
Coarse Adjustment RangeApproximately 20mm
Fine Adjustment RangeApproximate travel 0.002mm per division
Working StageDouble layer mechanical stage with graduated scale
Still Image Capture ResolutionAvailable with optional camera attachment
Video Capture ResolutionAvailable with optional camera attachment
Image FormatVisual only; photo attachment possible
Interpupillary Distance55-75mm adjustable
Objective Achromatic4x, 10x, 40x (spring), 100x (spring, oil)
CondenserAbbe condenser with iris diaphragm NA 1.25
Light SourceMirror (Plano-Concave) and sub-stage LED/halogen lamp

Company Details

Our ISO certified company, Sunil Brothers, is a competitive business entity that is constantly working hard under the vigil of Mr. Sunil Dhiman to meet the diverse equipment and many other requirements of our clients in the global. We specialize in designing and manufacturing premium grade Laboratory Instruments, Clean Room Equipment, Scientific Instruments, Hot Air Ovens, Inoculation Chambers, Tissue Culture Racks, Slide Cabinets, etc. Providing these with a guaranteed level of quality, we have become a respected manufacturer and exporter in the market. By exporting approximately 20% of our total production, we have gained a significantly huge clientele in numerous foreign markets we deal in. The goal is to constantly utilize best produ

Business Type

Exporter, Manufacturer, Supplier

Employee Count

8

Establishment

1988

Working Days

Monday To Sunday

GST NO

06AIKPK0469K1Z0

Related Products

Explore Related Categories

More Products From This Seller

Seller Details

GST

GST - 06AIKPK0469K1Z0

Premium Seller

Ambala Cantt, Haryana

Proprietor

Mr Sunil Dhiman

Members since

8 Years

Address

Plot No.- #4, Shanti Nagar, Kardhan, Ambala Cantt, Haryana, 133001, India

binocular microscope in Ambala Cantt

Report incorrect details

Compare With Similar Products

Buyer Feedback

3

3

3

Features

Anti-fungal coating, 360Adeg rotatable head, robust metallic body

Durable metal frame, anti-fungal optical components, precise mechanical stage, ergonomic design

Focus System

Coarse and fine coaxial adjustment

Coaxial coarse & fine focusing knobs

View Head

Binocular head, inclined and rotatable

Binocular, inclined at 45Adeg and 360Adeg rotatable

Spare Parts

Eyepiece, objectives, mirror, lamp

Objectives, eyepieces, fuse, mirror, bulb, dust cover, immersion oil

Theory

Other, Optical microscope for biological and laboratory analysis

Other, Pathological Binocular Microscope designed for high-precision laboratory analysis

Co-axial Binocular Microscope, Other

Drawtube

Binocular

Other, Binocular, 360Adeg rotatable, inclined at 45Adeg for comfortable viewing

Sensor

Not Applicable (Optical)

N/A (Not integrated with digital camera by default)

Resolution

Dependent on eyepiece and objective combination

Optical resolution based on objective and eyepiece combination

Interface

Mechanical adjustment knobs

Standard optical interfaces; mechanical stage controls

Focal Distance

Adjustable with coarse and fine focus

160 mm (standard optical tube length)

Magnification

40x, 100x, 400x, 1000x (using standard objectives and eyepieces)

40X to 1000X (with standard objectives and eyepieces)

Dimensions

Approx. 370mm x 135mm x 180mm (H x W x D)

Approx. 370mm x 190mm x 250mm

Focus Range

Coarse and fine adjustment, typically up to 25mm

Coarse and fine focusing mechanism

Eyepieces

Widefield 10x Pair

Paired Wide Field 10X (WF10x) Eyepieces

Eyepiece Tube

Inclined, 360Adeg rotatable

Binocular, Interpupillary distance adjustable from 55mm to 75mm

Illumination

Reflective mirror and sub-stage lamp

Built-in LED or Halogen illumination (6V/20W), adjustable brightness

Coarse Adjustment Range

Approximately 20mm

Approximately 20 mm range

Fine Adjustment Range

Approximate travel 0.002mm per division

0.002 mm precision movement

Working Stage

Double layer mechanical stage with graduated scale

Mechanical stage, size approximately 120mm A-- 125mm with coaxial controls

Still Image Capture Resolution

Available with optional camera attachment

N/A (not included in optical version)

Video Capture Resolution

Available with optional camera attachment

N/A (not included in optical version)

Image Format

Visual only; photo attachment possible

N/A (applies to digital models only)

Interpupillary Distance

55-75mm adjustable

Adjustable 55mm to 75mm

Objective Achromatic

4x, 10x, 40x (spring), 100x (spring, oil)

Achromatic objectives: 4X, 10X, 40X (SL), 100X (SL oil immersion)

Condenser

Abbe condenser with iris diaphragm NA 1.25

Abbe condenser, N.A. 1.25, with iris diaphragm & filter holder

Light Source

Mirror (Plano-Concave) and sub-stage LED/halogen lamp

6V/20W halogen or high-brightness LED, adjustable
