Battery Copper Busbar - Color: Brown

Battery Copper Busbars

Custom-Engineered for High-Current, Low-Voltage Battery & Energy Storage Systems

Overview :

* Designed for battery packs, EV modules, UPS systems, and energy storage units

* Manufactured using high-purity ETP or OFHC copper for superior performance

* Supports custom fabrication based on your design and drawings

* Finishing options: Bare, Tinned, Silver-Plated, Nickel-Plated

* Optional heat-shrink insulation sleeves for electrical safety and color coding

Key Advantages

Copper Properties :

* Material: ETP Grade (Cu-ETP) or OFHC Copper (Cu-OF)

* Purity: 99.9%

* Conductivity: Up to 101% IACS Ensures minimal energy loss and high thermal efficiency

Design & Fabrication

* Fully customizable:

* Drilled holes, CNC bending, custom lengths, lamination, and complex shapes

* Engineered to meet your exact electrical and mechanical needs

Finishing Options :

* Available finishes: Bare, Tinned, Silver-Plated, Nickel-Plated

* Enhances corrosion resistance, contact reliability, and service life

Insulation & Sleeving :

* Heat-shrink sleeves (RoHS-compliant) for :

* Electrical insulation

*Operator safety

* Color-coded identification (Red, Black, Blue, Yellow, Green)

Durability & Efficiency :

* Low contact resistance, high load endurance, and vibration resistance

* Withstands thermal stress and long operating cycles

Eco-Friendly :

* Made from 100% recyclable copper

* Ideal for sustainable energy storage and EV systems

Technical Specifications :

* Material: Cu-ETP / Cu-OF (Electrolytic / Oxygen-Free Copper)

* Purity: 99.9%

* Conductivity: Up to 101% IACS

* Thickness: 2 mm 12 mm

* Width: 10 mm 100 mm

* Length: Up to 2000 mm (custom lengths available)

* Finish Options: Bare / Tinned / Silver / Nickel Plated

* Insulation Options: Heat-shrink sleeve / PVC / Epoxy

* Color Sleeves: Red, Black, Blue, Yellow, Green

* Current Rating: 50A to 2000A+ (depending on size and design)

* Standards Compliance: IS, IEC, RoHS

Applications

* Lithium-Ion & Lead-Acid Battery Packs

* EV Battery Modules

* Battery Energy Storage Systems (BESS)

* Solar/Wind Power Storage Units

* Telecom Backup (UPS, Inverters)

* Railway, Marine, and Aerospace Power Units

* Industrial Control Panels & Automation Systems

Advantages Over Traditional Wiring :

* Higher current-carrying capacity

* Reduced voltage drop

* Compact & space-efficient layout

* Better thermal dissipation

* Cleaner, organized installations

* Greater mechanical strength & longevity
