Automatic Paper Straws Printing Machine

Type : Automatic Paper Straws Printing Machine
Max web width : 330mm
Max printing width : 320mm
Max unwinding dia : 1000mm
Max printing speed
(Production speed depending on process, job etc.) : 60m/min
Gear pitch : 3.175mm (1/8a )
Printing unit(IR drier) : 3 units
Printing repeat56T-112Ti 1T=3.175mmi
Air shaft diameter : 76mm
Printing plate diameter : 1.7mm
Mounting tape0.38mm
Speed ControlBy converter
Power Supply : 380V/3Phase/50HZ
Control System
Motor : 2.2 KW, Wannan
Converter : Yaskawa, Japan
Unwinding tension controller : ZXTEC
Rewinding tension controller :ZXTEC
Button switch Schneider
Electric Components CHINT or Schneider
Web guiding : ZXTEC
Configuration
Simple mounter : 1 pcs
Printing cylinder : 1 set (3 pcs)
Ceramic anilox roller : 1 set (3 pcs)
Tool box : 1 set
Measurement & Weight
Measurement : 3200*1160*2150mm
Weight : 2600kgs


450 Paper Straws Slitting Machine
Technical Parameter
Max web width450mm
Max unwinding dia1000mm
Slitting width10-18mm(un-adjustable)
18-450mm(adjustable)
Speed80m/min
Max rewinding dia450mm
Cutting precisionaL 0.5mm
Operator1 person
Speed ControlBy converter
Power Supply380V/3Phase/50HZ
Control System
Motor2.2KW, Lichao
Converter2.2KW, Schneider
Unwinding tension controllerZXTEC
Rewinding tension controllerZXTEC
Magnetic powderGuangtai
Web guiding sensorHENGWANG
Button switchSchneider
Circular1 set of 15mm width
1 set of 13.5mm and 14mm
Air cylinderJingwei
Configuration
Tool box1 set
Measurement & Weight
Measurement2850*1280*1320mm
Weight900kgs
